Deskripsi Produk

AMS Network, sebagai distributor UPS APC terpercaya, selalu mengutamakan kepuasan pelanggan. Kami tidak hanya menyediakan UPS APC SRT1000XLI dengan kualitas terbaik, tetapi juga memberikan layanan konsultasi yang menyeluruh untuk membantu Anda memilih produk yang tepat. Tim kami yang berpengalaman siap membantu Anda 24/7.

Main Specifications

• Run Time for Load:
  • 1000 W
  • Min-Max: 100-1000 W
  • 8 min 27s (Max. Capacity Used: 100%)
• Main Input Voltage: 230 V
• Product Type: Uninterruptible power supply (UPS)
• Other Input Voltage: 220 V, 240 V
• Main Output Voltage: 230 V
• Other Output Voltage: 220 V, 240 V
• Rated Power:
  • 1000 W
  • 1000 VA
• Input Connection Type: IEC 60320 C14
• Output Connection Type: 6 IEC 60320 C13
• Cable Length: 1.8 m
• Number of Cables: 1
• Provided Equipment:
  • CD with software
  • Communication cable
  • Documentation CD
  • Installation guide
  • Removable support feet
  • USB cable
  • Warranty card
• Range of Product: Smart-UPS On-Line

Batteries & Runtime

• Battery Type: Lead-acid battery
• Number of Battery Filled Slots: 1
• Number of Battery Free Slots: 0
• Battery Recharge Time: 3 hours
• Number of Battery Replacements: 1
• Battery Voltage: 48 V
• Battery Charger Power: 97 W rated
• Battery Life: 3-5 years
• Replacement Battery: APCRBC155
• Extended Runtime: 1

General

• UPS Type: Double conversion online
• Product Sub-family: High density
• Number of Power Module Free Slots: 0
• Number of Power Module Filled Slots: 0
• Redundant: No

Physical

• Colour: Black
• Dimensions (HxWxD): 43.2 cm x 8.5 cm x 50.5 cm
• Net Weight: 20.5 kg
• Mounting Preference: No preference
• Mounting Mode: Rack-mounted with kit
• Two Post Mountable: No
• USB Compatible: Yes
• Mounting Position: Vertical

Input

• Network Frequency: 40-70 Hz auto-sensing
• Input Voltage Limits:
  • 100-275 V (40% load)
  • 176-275 V

Output

• Maximum Configurable Power:
  • 1000 VA
  • 1000 W
• Output Frequency: 50/60 Hz +/- 3 Hz sync to mains
• Wave Type: Sine wave
• Harmonic Distortion: Less than 2%
• Crest Factor: 3:1
• Bypass Type: Built-in bypass

Conformance

• Product Certifications: CE, EAC, UK PSTI
• Standards:
  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018

Environmental

• Operating Temperature: 0-40 °C
• Relative Humidity: 0-95% non-condensing
• Operating Altitude: 0-10,000 ft
• Storage Temperature: -20-50 °C
• Storage Relative Humidity: 0-95% non-condensing
• Storage Altitude: 0-15,240 m
• Acoustic Level: 50 dBA
• Heat Dissipation: 317 Btu/h
• IP Degree of Protection: IP20

Communications & Management

• Free Slots: 1
• Alarm: Audible and visible alarms, prioritized by severity
• Emergency Power Off: Yes

Surge Protection and Filtering

• Surge Energy Rate: 432 J

Packing Units

• Package Type: PCE
• Number of Units in Package: 1
• Package Dimensions (HxWxL): 24.5 cm x 69.0 cm x 59.5 cm
• Package Weight: 32.58 kg

Contractual Warranty

• Warranty: 3 years repair or replace (excluding battery) and 2 years for battery
